FEULING OIL PUMP CORP. Endurance Beehive Valve Springs 1101
SKU 1101
Sold out
Original price
$0
Original price
$646.95
-
Original price
$646.95
Original price
Current price
$646.95
$646.95
-
$646.95
Current price
$646.95
FREE Shipping Over $99*
- FREE Shipping on orders over $99 -Excludes Bulky Items
- All prices are in Australian Dollars
- See delivery info below
FEULING ENDURANCE BEEHIVE valve springs are a direct bolt in replacement up to 650 lift camshafts no spring seat machining required. Machined from a premium grade Hi-tensile chrome silicon single conical ovate wire, shot-peened with a specially processed thermal heat treat and super NexTex finish to give these valve springs the needed fatigue life to exceed the high demands of V-Twin engines from stock to performance.
FEULING BEEHIVE valve springs use a much smaller and lighter weight retainer which drastically reduces the valve weight creating a much quicker revving and smoother motion than comparable dual valve springs.
FEULING endurance springs are a direct bolt-in replacement up to 650 cam lift no machining or rocker box clearancing required.
Eliminate valve spring separation, maximize stability, reduce valve-train noise & harmonics!
Available for 5/16 and 7mm valves
FEULING BEEHIVE valve springs must be installed at the correct OPEN HEIGHT, matching max lift to the open height spec of the valve springs
Kits include: FEULING ENDURACE BEEHIVE valve springs, lightweight 7 Degree Titanium heat treated retainers, machined spring seats, seat shims, valve locks and a set of premium Viton valve seals equipped with a spring loaded valve stem wiper system.
Dont get stung by inferior valve springs!
Quicker Revving - Smoother Motion - Light Weight Ti Retainers - Bolt in up to 650 Lift
Specs
FEULING BEEHIVE valve springs use a much smaller and lighter weight retainer which drastically reduces the valve weight creating a much quicker revving and smoother motion than comparable dual valve springs.
FEULING endurance springs are a direct bolt-in replacement up to 650 cam lift no machining or rocker box clearancing required.
Eliminate valve spring separation, maximize stability, reduce valve-train noise & harmonics!
Available for 5/16 and 7mm valves
FEULING BEEHIVE valve springs must be installed at the correct OPEN HEIGHT, matching max lift to the open height spec of the valve springs
Kits include: FEULING ENDURACE BEEHIVE valve springs, lightweight 7 Degree Titanium heat treated retainers, machined spring seats, seat shims, valve locks and a set of premium Viton valve seals equipped with a spring loaded valve stem wiper system.
Dont get stung by inferior valve springs!
Quicker Revving - Smoother Motion - Light Weight Ti Retainers - Bolt in up to 650 Lift
- SEAT Lbs. / INSTALLED HEIGHT
- 198 Lbs. @ 1.685 (0.535 Lift)
- 194 Lbs. @ 1.703 (0.553 Lift)
- 190 Lbs. @ 1.724 (0.574 Lift)
- 187 Lbs. @ 1.754 (0.604 Lift)
- 185 Lbs. @ 1.780 (0.630 Lift)
- 160 Lbs @ 1.800 (0.650 Lift)
- 375 Lbs @ 1.150 OPEN HEIGHT
-
Coil Bind @ 1.100
NOTE: Fits Twin Cam Screamin' Eagle Heads with 5/16" valve stems with standard keeper grooves and .530" diameter valve guides, springs, titanium retainers, seats, seals, keepers, and seat shims
Specs
| PRODUCT NAME | SPRING KIT |
| TYPE | VALVE |
| APPLICATION | EXHAUST / INTAKE |
| STYLE | OVATE WIRE BEEHIVE |
| MODEL | ENDURANCE BEEHIVE |
| COLLAR MATERIAL | TITANIUM |
| MATERIAL | STEEL |
| STEM DIAMETER | 7.056 MM |
| SPRING LIFT | 0,650" / 0.650" |
| UNITS | KIT |
| RIDING STYLE | STREET |
