FEULING OIL PUMP CORP. Camchest Kit - HP+ - Twin Cam '99-'06 - 7224P

BULLETPROOF HP+ CAMCHEST KIT!
FOR HYDRAULIC CHAIN TENSIONER CONVERSION UPGRADE

FEULING complete camchest kits include all necessary components from top to bottom of the camchest conveniently packaged under 1 part #. These combination kits not only ensure each individual part is designed to work and function together but to do so in total harmony. These camchest kits take the guess work out of the ordering process and guarantees the engine builder maximum reliability, peak performance and the coolest engine and oil temperatures obtainable.

HP+ Complete Conversion Camchest Kits include: FEULING HP+ high volume Oil pump, high flow Camplate, REAPER Series Conversion Camshafts, HP+ hydraulic roller Lifters, One Piece Pushrods, hydraulic tensioners, sprockets, roller chains, cam sprocket spacers, Timken Cam Bearings, Gaskets, O-rings, Exhaust gaskets, ARP fasteners, washers, moly paste, Loctite and hardware.

Camchest kits are available in FEULING HP+ and RACE SERIES combinations and with gear drive or chain drive REAPER camshafts. Fitments available for 99-17 Twin Cam engines. 25-35 degree cooler engine temperatures, 15-30 degree cooler oil temperatures, 15-30 more pounds of oil pressure, quieter and smoother engine operation, eliminate wet sumping, blow by and oily air cleaners.

UPDATE YOUR OLD MECHANICAL STYLE CAMS AND TENSIONERS TO THE NEW HYDRAULIC STYLE TENSIONER SYSTEM

Conversion camshafts for 99-06 Twin Cam engines. These camshafts utilize the 99-06 inner cam journals with the 07-16 outer cam journals allowing the use of the 07-1 camplates, oil pump, hydraulic chain tensioners and chain drive system.

543 CAMS - The Freeway Flyer, a great camshaft for those who want more top end power than our 525 cam without sacrificing low end torque. Extremely smooth cam lobe layout maintains quiet valvetrain and produces the smoothest cruise power band available. Excellent bolt in camshaft for stock to mild 96 and 103 engines and works well in 88 & 95 engines. This cam is easy starting, increases throttle response and fuel mileage. Responds well to increased compression ratio, performance exhaust and a high flow air cleaner. Performance valve springs are required on 99-04 engines and performance pushrods and lifters are recommended but not required. RPM 1,900 - 6,000

• All necessary components from top-to-bottom of the camchest
• Provide maximum reliability, longevity, peak performance, and the coolest engine and oil temperatures obtainable
• Quieter and smoother engine operation
• Increase oil pressure, scavenge volume and engine oil flow
• 25°-35° cooler engine temperatures
• 15°-30° cooler oil temperatures
• 15-30 more PSI of oil pressure
• Eliminate wet sumping, blow by and oily air cleaners
• Includes Feuling® HP+® high-volume oil pump, high-flow billet cam plate, REAPER® Series camshafts, HP+® hydraulic roller lifters, Fast Install® pushrods, Timken®/Koyo® bearings, gaskets, O-rings, hardware, ARP® fasteners, washers, moly lube and Loctite®
• Installation of gear drive cams will require separate purchase of S&S or Andrews 4-gear drive kit.


  NOTE:Conversion chain drive kits update early mechanical-style tensioner systems to the new late-style hydraulic tensioner chain drive system; these kits utilize conversion Reaper® camshafts which have '99-'06 inner-cam journals matched with '07-'17 outer-cam journals, allowing the use of the '07-'17 cam plate and hydraulic chain drive tensioner system; hydraulic chain drive components purchased separately.

  NOTE:
  1900 - 6000 rpm power range.
  Includes:
  • HP+ High Volume Oil Pump
  • High Flow Camplate
  • Reaper Series Conversion Camshafts
  • HP+ Hydraulic Roller Lifters
  • One Piece Pushrods
  • Hydraulic Tensioners
  • Sprockets
  • Roller Chains
  • Cam Sprocket Spacers
  • Timken Cam Bearings
  • Gaskets
  • O-Rings
  • Exhaust Gaskets
  • ARP Fasteners
  • Washers
  • Moly paste
  • Loctite
  • Hardware



Specs
