FEULING OIL PUMP CORP. Chain Drive Reaper Cam - 574 Series - Harley-Davidson '06-'17 - 1009
🚚 Estimated Delivery: 24 Oct - 31 Oct
CONFIRM FITMENT BEFORE ORDERING
Please confirm fitment for your bike below as we do not accept returns on parts ordered incorrectly.
574 CAMS - Wicked power band for modified engines and an excellent bolt in for stock 96, 103 & 110 engines. This is a great all around camshaft with solid low end performance and mind blowing mid and top end power. Extremely smooth cam lobe design creates a very smooth valve-train motion. Responds very well to modified cylinder heads, increased compression ratio, performance exhaust and intake systems. Performance valve springs are required on 99-04 engines and performance pushrods, lifters and clutch are recommended. RPM 2,100 - 6,500
FITS: HARLEY DAVIDSON TWIN CAM ENGINES 2007 - 2017, Including 2006 Dyna models
Feuling does not recommend tuning beyond stock emissions standards.
FITS:
TC 07 - 17 Includes 06 Dyna models, 574 Intake, 574 Exhaust, Direct bolt in for 05-17 engines, factory valve springs can be used, performance pushrods and lifters are recommended. RPM 2,100 - 6,400
- Power band for modified engines and an excellent bolt-in for stock 96", 103" and 110" engines
- Responds well to modified cylinder heads increased compression ratio, performance exhaust and intake systems
- Extremely smooth cam-lobe design creates a smooth and quiet valvetrain
- 2100-6500 RPM power range
- Performance valve springs required on '99-'04 engines and performance pushrods and lifers recommended.
Specs
| PRODUCT NAME | CAMSHAFT |
| TYPE | CHAIN |
| APPLICATION | EXHAUST / INTAKE |
| MODEL | REAPER |
| GRIND | 574 SERIES |
| INTAKE OPEN | 15° |
| INTAKE CLOSE | 45° |
| INTAKE LIFT | 0.574" |
| INTAKE DURATION | 240° |
| EXHAUST LIFT | 0.574" |
| EXHAUST DURATION | 255° |
| EXHAUST OPEN | 61° |
| EXHAUST CLOSE | 14° |
| UNITS | PAIR |
| RIDING STYLE | STREET |
